FOUR SHAFT SHREDDER

APPLICATIONS:

  • Barrel products: plastic barrel, metal barrel, paint barrel
  • Garbage: domestic garbage, medical waste, etc
  • Plastic products: plastic frame, plastic block, plastic can
  • Metal products: aluminum profile, oil filter, metal tank
  • Paper: newspaper, cardboard, corrugated paper, copy paper
  • Electronic appliances: refrigerator, circuit board, TV shell
  • Glass products: glass wool, glass cup, glass bottle

EQUIPMENT INTRODUCTION

model: FS series

FS series Four Shaft Shredder has advantages of strong usage universality, accessory standardization, modularization design and high interchangeability. It fits for shredding plastic drums, plastic bottles, metal drums, circuit boards, household waste, hazardous waste etc. This design can create the maximum benefit and control output material size according to customers' different requirements & shred materials.

VIDEO

Four shaft shredder FS100120

Different materials and different tool rolls

Rotor

TECHNICAL FEATURES

  • Through the EU CE certification, the whole machine technology comes from Italy,
  • The standard modular design is adopted, and the interchangeability of parts is good,
  • The main knife is made of special alloy steel by special special process,
  • The auxiliary knife is refined from die forging,
  • It has good wear resistance and high strength,
  • The driving part is driven by an intermediate gear to form a differential relationship,
  • The screen is easy to disassemble. It has beautiful appearance and compact structure.

PARAMETERS

MODEL   +

CASES

FS8080

FS10080

FS130100

FS160160

DATA DOWNLOAD

DOWNLOAD

Item       Model

FS8080

FS10080

FS100100

FS100120

FS130100

FS130120 FS160160

Motor Power (kw)

2×11

2×18.5

2×18.5

2×22

2×15+2×22

2×15+2×30

2×30+2×45

Main Blade Thickness (mm)

18.5

40

40

40

50

50

50

Main Blade Tactical Diamete (mm)

φ245

φ320

φ320

φ320

φ430

φ430

φ534

Main Blade (pcs)

42

21

26

31

20

24

32

Main Shaft Rev (rpm)

16-25

16-25

16-25

16-25

10-15

10-15

10-15

Height of discharge port (mm)

650

980

980

980

1000

1000

1400

Screen Mesh (mm)

φ25

φ40

φ40

φ40

φ60

φ60

φ60

Cutting Chamber (mm)

800×800

1000×800

1000×1000

1000×1200

1300×1000

1300×1200

1600×1600

Dimension (mm)

2180×1200×2065

2410×1400×2730

2610×1400×2730

2810×1400×2730

3200×1650×2930

3400×1650×2930

4360×2200×3630

Weigh (kg)

Approx 2000

Approx 5000

Approx 5500

Approx 6000

Approx 11500

Approx 12500

Approx 18000
